If you love gardening, you know how demanding the work can be. To craft a garden takes time, sweat, and skills. As the body becomes frailer, using power cutters, getting on your knees and backing up, and collecting cuttings grow into an arduous task. Now, a new artificial intelligence project to improve your average robot lawnmower and help you with the gardening tasks is on the way. The TrimBot2020 project explores the underlying robotics technologies and prototypes the next generation of intelligent gardening robots.

Figure 1: Trimbot2020 prototype. The robot will navigate over different terrain, approach rose bushes, hedges, and boxwood topiary, to trim them to an ideal shape.

A straightforward gardening task, let’s say bush trimming, involves three basic steps. First, the gardener detects the bush, then s/he approaches it, and finally, the bush is trimmed. The TrimBot2020 wants to automate this process [1]. The project develops intelligent outdoor hedge, rose and bush trimming capabilities, allowing the robot to navigate over different terrains and restore the hedges to a tidy shape. At the Computer Vision Lab at the University of Amsterdam, we design real-time intelligent algorithms for 3D data analysis and scene-understanding tasks for the TrimBot2020 project.

When traditional formulas fail

Nowadays, machine learning is at the core of artificial intelligence research and most of its modern algorithms are based on artificial neural networks (ANNs). They are particularly useful when a task cannot be solved by traditional algorithms that expect a set of instructions or formulas. Think, for example, of the chore of detecting a bush. Humans are able to do it through experience, but it is impossible to create a set of instructions for the task. An ANN, on the other hand, can learn how to distinguish bushes by examining a set of images. It is a challenging task for a computer: what we observe as images is just a set of numbers (Red, Green, and Blue color values) for computers.

Convolutional Neural Networks (CNNs), a class of ANNs, are very successful for computer vision tasks. They examine a lot of images to make the association between those images and their labels. In order to function properly, CNNs need large-scale image datasets, which require considerable effort to collect and label. To develop and test our algorithms, we have created the first ever large-scale synthetic dataset featuring plants and objects under different illumination conditions found in gardens. As of now, the dataset contains 400,000 synthetic garden images with corresponding labels (examples in Fig.2).

Figure 2. Images from the synthetic Natural Environment Dataset featuring plants and objects under varying light. Notice how the appearance of garden objects changes with illumination.

Throwing light upon the garden

Recall the task of bush trimming. The first step is to detect the bush. However, the imaging conditions of gardens may vary significantly over, even small, periods of time influencing the appearance of garden objects and scenes. The incoming light to a garden scene is constantly changing due to the weather conditions and the position of the sun and clouds. As a result, garden objects may contain shadows, specular highlights, and illumination changes. Those changes affect the pixel (RGB) values of images such that the appearance of a bush, for example, fluctuates during the day: sometimes it is brighter due to direct sunlight, others it appears dimmer due to shadows. People distinguish those changes easily, but computers just see numbers (RGB values) without any context. So, for a CNN to recognize a bush, it needs to examine quite a number of garden images that include lighting variation. Therefore, instead of analyzing countless images, a full illumination invariant representation can help CNN to ignore those illumination effects.

To achieve this, we need to break down the images into smaller parts such as reflectance (albedo) and shading (illumination). This method is called intrinsic image decomposition and it is based on the assumption that scenes are basically composed of object shapes and their interactions with the light and their material colors [2], (Fig. 2). While the albedo intrinsic only contains the true color of objects in a scene, the shading component includes geometry and illumination effects. Thus, using albedo images instead of original RGB images can be favorable.

An image is decomposed such that pixel-wise multiplication of albedo and shading components gives the original image back. Therefore, manipulating only the colors or only the light effects of a scene becomes possible. Furthermore, it allows us to recreate new images by individually manipulating these color and light effects, which is a useful feature for photo-realistic editing tasks, for instance. In the Computer Vision Lab, we study means to create real-time algorithms that are not affected by outdoor illumination [3].

How to pilote a robot

The next task for TrimBot2020 is to detect and reach the bushes without hitting any obstacles. Remember that robots only observe numeric pixel (RGB) values. For a robot to detect its surroundings, we use semantic segmentation, a process that involves grouping and labeling all pixels of an image.

Because changes in the illumination alter the pixel values of an image, they may have a negative influence on the segmentation. For example, in Figure 2, the appearance of the bushes in the first and last rows are quite different because of the different illumination effects. But we know that the albedo image is invariant to illumination and thus we can use it for segmentation tasks. Moreover, semantic segmentation may be beneficial for albedo prediction. Each label constrains the color distribution and is expected to reflect that property to class-specific albedo values. For example, bushes exhibit certain green colors. Thus, semantic segmentation and intrinsic image decomposition can complement each other.

Figure 3: Our method is able to capture proper semantic segmentation along with thin structures and achieves sharper results

To achieve that, we design a CNN architecture that is capable of jointly learning intrinsic image decomposition (Fig. 3) and semantic segmentation (Fig. 4) by using the synthetic garden dataset. The results show mutual benefits when performing two tasks in joint manner for natural scenes. In this way, TrimBot2020 is able to make decisions based on pixel labels. For example, if there is an obstacle, such as a rock or a hole, on the path, it can avoid it or detect and approach a bush to trim it [4].

Figure 4: Our method captures better colors and sharper outputs, and handles illumination effects better for albedo images

Robotics technology is expected to be dominant in the coming decade. According to a report from the International Federation of Robotics, the number of household domestic robots will hit 31 million by the end of 2019; floor cleaning robots, lawn mowers and edutainment (a word introduced in the nineties to describe education and entertainment tasks) robots currently have the biggest market share but the next generation of robots will very likely have greater capabilities, especially in the interaction with humans and the environment.

Robotic kitchen assistants, home-butlers, pool cleaners, laundry folders, and many other autonomous intelligent robots to help us with our daily chores are around the corner. As for non-domestic fields, autonomous security robots and self-driving vehicles for local goods transportation have already been deployed in the U.S. Additionally, agricultural robotic systems are already vastly used in the Netherlands and all around the world for horticulture, weed control, harvesting, and fresh supply chains. As for the TrimBot2020, the motion and manipulation skills and the perception of plants and obstacles under varied weather conditions are clear. At the Computer Vision Lab, the expectation is that the TrimBot project will increase Europe’s market share in domestic service robots and will improve technology readiness levels of robotics technologies.

References:
[1] N. Strisciuglio, R. Tylecek, M. Blaich, N. Petkov, P. Biber, J. Hemming, E. van Henten, T. Sattler, M. Pollefeys, T. Gevers, T. Brox, and R. B. Fisher. Trimbot2020: an outdoor robot for automatic gardening. In International Symposium on Robotics, 2018.
[2] H. G. Barrow and J. M. Tenenbaum. Recovering intrinsic scene characteristics from images. Computer Vision Systems, pages 3–26, 1978.
[3] A. S. Baslamisli, T. T. Groenestege, P. Das, H. A. Le,S. Karaoglu, and T. Gevers. Joint learning of intrinsic images and semantic segmentation. In European Conference on Computer Vision, 2018.
[3] A. S. Baslamisli, H. A. Le, and T. Gevers. Cnn based learning using reflection and retinex models for intrinsic image decomposition. In IEEE Conference on Computer Vision and Pattern Recognition, 2018.

Anil Baslamisli
I completed my Bachelor’s degree in computer engineering with honors at Middle East Technical University, Northern Cyprus Campus, in 2014. The idea of creating smart machine algorithms intrigued me to learn more about them. I earned my Master’s degree with distinction from Tampere University of Technology, Finland, in 2016 and performed my thesis “Camera Sensor Invariant Auto White Balance Algorithm Weighting” under the supervision of Prof. Moncef Gabbouj, in collaboration with Intel. During my studies, I also carried out an internship at Microsoft Finland, where I worked on image sharpness optimization and auto white balance problems. I really enjoyed my time working on different computer vision-related tasks such that I was contributing to solving daily life problems. The whole experience increased my enthusiasm to learn more and contribute to society. This led me to my current position, where I am doing my Ph.D. at the University of Amsterdam under the supervision of Prof. Theo Gevers. We do computer vision research on scene understanding and analysis tasks.
